XN - XD Series Data Table

XN SERIES

Picture	Item #	Model	Voltage	Phase	Nominal Power		Performance		Outlet	Solid Passage	Data Sheet
Picture	Item #	Model	Voltage	Phase	HP	kW	Q (G/min)	H (ft.)	In.	In.	Data Sheet
	5337128	XN 03M32	110V	Single phase	0.33	0.25	42	29	1 1/4	0.4
	5337131	XN 03M32	220V	Single phase	0.33	0.25	42	29	1 1/4	0.4
	5337129	XN 03MA32	110V	Single phase	0.33	0.25	42	29	1 1/4	0.4
	5337132	XN 03MA32	220V	Single phase	0.33	0.25	42	29	1 1/4	0.4
	5337130	XN 03MS32	110V	Single phase	0.33	0.25	42	29	1 1/4	0.4
	5337133	XN 03MS32	220V	Single phase	0.33	0.25	42	29	1 1/4	0.4

Picture	Item #	Model	Voltage	Phase	Nominal Power		Performance		Outlet	Solid Passage	Data Sheet
Picture	Item #	Model	Voltage	Phase	HP	kW	Q (G/min)	H (ft.)	In.	In.	Data Sheet
	5337116	XD 07M4A40	110V	Single phase	0.75	0.55	73	29	1 1/2	0.3
	5337136	XD 07M4A40	220V	Single phase	0.75	0.55	73	29	1 1/2	0.3
	5337117	XD 10M4A40	220V	Single phase	1	0.75	86	36	1 1/2	0.3
	5337135	XD 10M4A40	220V	Single phase	1	0.75	86	36	1 1/2	0.3
	5337118	XD 15M4A40	220V	Single phase	1.5	1.1	92	39	1 1/2	0.3
	5337119	XD 15T40	220V	Three phase	1.5	1	92	52	1 1/2	0.3
	5337120	XD 20T40	220V	Three phase	1.5	1	110	66	1 1/2	0.3
	5337120	XD 20T40	480V	Three phase	1.5	1	110	66	1 1/2	0.3
